How do Floor Heating Systems Work?
Heating Mats – DWM
How Radiant Floor Heating Systems Work:
Radiant heating systems work with thermal mass. This means that it heats the things around it, which then radiate the heat outward. So, for example, a heating cable will heat thinset and tile, then stop. And the thinset and tile will release that heat in the room.
Because thermal mass is very stable (unlike hot air from a furnace), radiant heat is much more efficient. You could open the windows in the winter but your tile floor would still be at 80 degrees. Once you close the window, comfort would resume immediately. With a furnace, it would have to kick in and work hard to replace the cold air with warm air all over again.
More Resources:
Want to see our products in action? Visit our YouTube Channel for tech tips, installation videos, and more!
For more information on our floor heat products, view the Literature Page on our website.
Interested in reading more? Head over to our blog post on this topic for more detail.
